ABSTRACT One defining goal of synthetic biology is the development of engineering-based approaches that enable the construction of gene-regulatory networks according to ‘design

specifications’ generated from computational modelling1,2,3,4,5,6. This approach provides a systematic framework for exploring how a given regulatory network generates a particular

phenotypic behaviour. Several fundamental gene circuits have been developed using this approach, including toggle switches7 and oscillators8,9,10, and these have been applied in new contexts

such as triggered biofilm development11 and cellular population control12. Here we describe an engineered genetic oscillator in _Escherichia coli_ that is fast, robust and persistent, with

tunable oscillatory periods as fast as 13 min. The oscillator was designed using a previously modelled network architecture comprising linked positive and negative feedback loops1,13. Using

a microfluidic platform tailored for single-cell microscopy, we precisely control environmental conditions and monitor oscillations in individual cells through multiple cycles. Experiments

reveal remarkable robustness and persistence of oscillations in the designed circuit; almost every cell exhibited large-amplitude fluorescence oscillations throughout observation runs. The

oscillatory period can be tuned by altering inducer levels, temperature and the media source. Computational modelling demonstrates that the key design principle for constructing a robust

oscillator is a time delay in the negative feedback loop, which can mechanistically arise from the cascade of cellular processes involved in forming a functional transcription factor. The

positive feedback loop increases the robustness of the oscillations and allows for greater tunability. Examination of our refined model suggested the existence of a simplified oscillator

design without positive feedback, and we construct an oscillator strain confirming this computational prediction. Access through your institution Buy or subscribe This is a preview of
